Brother DCP-B7500D Service Manual

1-8
Confidential
Model
MFC-L2730DW
MFC-L2732DW
MFC-7895DW
MFC-7890DN
MFC-B7700D
MFC-L2750DW
MFC-L2750DWXL
MFC-L2751DW
MFC-L2752DW
MFC-L2770DW
MFC-L2771DW
Warm up Time
(From Sleep Mode)
Less than 9 sec.
at 73.4F / 50%
(23°C / 50%)
Less than 4.0 sec.
at 73.4F / 50%
(23°C / 50%)
Less than 9 sec.
at 73.4F / 50% (23°C / 50%)
Less than 4.0 sec.
at 73.4F / 50%
(23°C / 50%)
Warm up Time
(From Power ON)
Less than 28 sec. at 73.4F / 50%
(23°C / 50%)
Less than 27 sec.
at 73.4F / 50%
(23°C / 50%)
(for MFC-B7700D)
Less than 28 sec.
at 73.4F / 50%
(23°C / 50%)
(for MFC-7890DN)
Less than 28 sec. at 73.4F / 50%
(23°C / 50%)
FPOT
(From Ready Mode
and Standard Tray)
Less than 8.5
sec. at 73.4F
(23°C) / 230V
Less than 7 sec.
at 73.4F (23°C) /
230V
Less than 8.5 sec.
at 73.4F (23°C) / 230V
Less than 7 sec.
at 73.4F (23°C) /
230V
FPOT
(From Sleep Mode
and Standard Tray)
Less than 17.5
sec. at 73.4F
(23°C) / 230V
Less than 11 sec.
at 73.4F (23°C) /
230V
Less than 17.5 sec.
at 73.4F (23°C) / 230V
Less than 11 sec.
at 73.4F (23°C) /
230V
Mono Print Speed
(A4/Letter)
Up to 34/36 ppm
(Quiet Mode: Up to 13/13 ppm)
Full Color Print
Speed (A4/Letter)
N/A
Mono Duplex Print
Speed (A4/Letter)
16/17 sides per minute
(8/8.5 sheets per minute)
Full Color Duplex Print
Speed (A4/Letter)
N/A
Processor 600 MHz
Back up Clock Up to 60 hours
Up to 2 hours
(for MFC-B7700D)
Up to 60 hours
(for MFC-7890DN)
Up to 60 hours
Carton Dimensions
(W x D x H)
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
608 x 570 x 434 mm
23.9" x 22.4" x 17.1"
580 x 570 x 434 mm
22.8" x 22.4" x 17.1"
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
608 x 570 x 434 mm
23.9" x 22.4" x 17.1"
Machine Dimensions
(W x D x H)
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
481 x 426.5 x 318.5 mm
18.9" x 16.8" x 12.5"
481 x 398.5 x 318.5 mm
18.9" x 15.7" x 12.5"
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
410 x 426.5 x 318.5 mm
18.9" x 16.8" x 12.5"
Weight w/ Carton
14.7 kg / 32.5 lb
(MFC-L2730DW for
US/EU/OCE)
14.9 kg / 32.8 lb
(for MFC-L2732DW)
TBD
(MFC-L2730DW for
LTN)
16.2 kg / 35.8 lb
15.5 kg / 34.3 lb
(MFC-B7700D)
TBD
(MFC-7890DN)
14.9 kg / 32.9 lb
(MFC-L2750DW for
US/EU/OCE,
L2751DW for ASA)
15.0 kg / 33.0 lb
(MFC-L2751DW for
EU)
15.3 kg / 33.8 lb
(MFC-L2750DW for
ASA)
15.5 kg / 34.1 lb
(MFC-L2750DWXL)
TBD
(MFC-L2750DW for
LTN, L2752DW)
15.9 kg / 35.1 lb
(MFC-L2770DW for
OCE)
16.0 kg / 35.3 lb
(MFC-L2771DW)
16.2 kg / 35.8 lb
(MFC-L2770DW for
ASA)
Weight w/o Carton,
w/ toner/drum
11.8 kg / 26.0 lb
(MFC-L2730DW for
US/EU/OCE,
L2732DW)
TBD
(MFC-L2730DW for
LTN)
12.8 kg / 28.2 lb
12.1 kg / 26.7 lb
(MFC-B7700D)
TBD
(MFC-7890DN)
12.0 kg / 26.5 lb
(MFC-L2750DW for
US/EU/OCE,
L2751DW, L2752DW)
12.2 kg / 26.9 lb
(MFC-L2750DW for
ASA)
12.6 kg / 27.7 lb
(MFC-L2750DWXL)
TBD
(MFC-L2750DW for LTN)
12.7 kg / 28.0 lb
(MFC-L2770DW for
OCE, L2771DW)
12.9 kg / 28.4 lb
(MFC-L2770DW for
ASA)
Weight w/o Carton
and toner/drum
10.7 kg / 23.6 lb
(MFC-L2730DW for
EU, L2732DW)
10.9 kg / 24.0 lb
(MFC-L2730DW for
US/OCE)
TBD
(MFC-L2730DW for
LTN)
11.9 kg / 26.2 lb
11.2 kg / 24.7 lb
(MFC-B7700D)
TBD
(MFC-7890DN)
10.9 kg / 24.0 lb
(MFC-L2750DW for
EU/ASA, L2751DW
for EU, L2752DW)
11.1 kg / 24.5 lb
(MFC-L2750DW for
US/OCE, L2750DWXL,
L2751DW for ASA)
TBD
(MFC-L2750DW for LTN)
11.6 kg / 25.6 lb
(MFC-L2770DW for
ASA, L2771DW)
11.8 kg / 26.0 lb
(MFC-L2770DW for
OCE)
Specifications are subject to change without notice.

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
