1. About GT-3 Series
1-3-7-1. Display
The following image indicates that GT-3 has received a print data and ready to print. The Display indicates
Job, printer status and the information needed for printing operations.
01e0026Y
No. Item Shown Description
1
Job Name
Shows the indentified name of the print data, which is automatically set by
Printer Driver.
2
Job Comment
Shows the 30 characters of the Job Comment set by the operator with
Printer Driver.
3 Amount of Ink
Required
Shows how much ink (cc) is required for making one print of the received
data.
Shows warning message(s) if necessary.
4 Platen Size Shows Platen Size set by Printer Driver.
5
Number of Platen
Move
Shows the number of the Platen Move (loading/unloading) in printing one
print data.
6 Number of Print Shows the number of prints completed of the print data.
7 Printer Status Shows the printer status.
8 Amount of Ink
Remained
Shows amount of ink remained in each cartridge, from the left, W1, W2, W3,
W4 , Black (K), Magenta (M), Cyan (C) and Yellow (Y).
It flashes when ink is low. Prepare the new cartridge(s).
9 Uni-Directional Print
Icon
Shows when the printer or the print data is set to Uni-directional printing.
10 Number of White
Print Head Icon
Shows how many White Print Heads are used in printing one print data.
11 Resolution Icon Shows the resolution of the print data.
<Note> When one or more errors are detected, error message(s) will be displayed instead.
8
GT-3 Series
To Next Page
