Brother GT-3 Series Service Manual

6. Replacing Parts
(3)
(3)
Check the height here
11. Mount the Wi
per Cleaners.
12. Mount the Cover DB. (Refer to “6-1-2. Assembling/Disassembling of the Covers”.)
13. Turn ON the printer.
14. Select the menu [ Maintenance ] > [ Nozzle Cleaning ] and press the OK Button.
The Platen and the Carriage will move. The message is shown as below.
15. Turn O
FF the printer.
16. Open the Front Cover (Cover UF) with both hands until it is locked with the stopper.
17. Confirm the Nozzle Plate (12) is wiped clean with the hand mirror.
Crashless Plate (13) has an ink mark of the cap.
Confirm that the Wiper can wipe off the ink as shown in the right photo, where no ink pool left around the
tiny nozzles on the Nozzle Plate. Check quickly or the ink may run from the nozzles.
GT-3 Series
202
18. Push the Stop Lever to release the lock when you close the Front Cover (Cover UF) with both hands.
(12
19. Turn O
N the printer, and initialization will start and the Carriage will move to the original position (on the
Maintenance Unit).
20. Turn OFF the printer.
)
(12) (13)
