Brother HL-5270DN Network User's Guide

Introduction
1 - 4
1
Types of network connection
Wired network connection example
Generally speaking, there are two types of network connection: Peer-to-Peer environment and a Network
Shared environment.
Peer-to-Peer printing using TCP/IP
In a Peer-to-Peer environment, each computer directly sends and receives data to and from the Brother
printer.
■ In a smaller network of 2 or 3 computers, we recommend the Peer-to-Peer printing method as it is easier
to configure than the Network Shared printing method described on the following page. See Network
Shared printing on page 1-5.
■ Each computer must use the TCP/IP Protocol.
■ The Brother printer needs to have an appropriate IP address configuration.
■ If you are using routers, the Gateway address must be configured on the computers and the Brother
printer.
■ The Brother printer can also communicate with Macintosh
®
. (TCP/IP compatible operating systems)
Router
Windows
®
Windows
®
TCP/IP TCP/IP
Windows
®
Network printer

Brother HL-5270DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Maximum internal memory	544 MB
Number of print cartridges	1
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	IPv4, IPv6
Networking features	Ethernet 10/100Base-TX
Power consumption (active)	610 W
Display	LCD
Sustainability certificates	ENERGY STAR
Power consumption (standby)	80 W
Power consumption (PowerSave)	9 W

Weight and Dimensions

Dimensions (WxDxH)	393 x 384 x 259 mm
