Network printing from Windows
®
: basic TCP/IP Peer-to-Peer printing
4 - 7
4
Adding a second Brother LPR port
You do not re-run the install program to add a new Brother LPR port. Instead, go to the Start button, select
Settings, and open the Printers window. Click the icon of the printer that you wish to configure, select File
from the menu bar, and then Properties. Click the Details tab and then the Add Port button. In the Add Port
dialog, select the Other radio button and then highlight Brother LPR port. Click OK and enter the port name.
The default port name is BLP1. If you have already used this name, you will get an error message if you try
to use it again, in which case use BLP2, etc... Once you have specified the port name, click the OK button.
You will then see the Port Properties dialog.
Enter the IP address of the printer that you wish to print to and click OK. You should now see the port that
you have just created in the Print to the following port setting of the printer driver.
Other sources of information
See Chapter 2 of this User’s Guide to learn how to configure the IP address of the printer.

Table of Contents

Other manuals for Brother HL-5270DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-5270DN and is the answer not in the manual?

Brother HL-5270DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 9, 16, 25
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Economical printingYes
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)28 ppm
Maximum internal memory544 MB
Number of print cartridges1
Total input capacity250 sheets
Total output capacity100 sheets
Multi-Purpose tray input capacity50 sheets
Maximum print size210 x 297 mm
Paper tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Supported network protocols (IPv4)IPv4, IPv6
Networking featuresEthernet 10/100Base-TX
Power consumption (active)610 W
DisplayLCD
Sustainability certificatesENERGY STAR
Power consumption (standby)80 W
Power consumption (PowerSave)9 W
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)393 x 384 x 259 mm
