2 - 6 ASSEMBLY AND CONNECTIONS
BHL-FB-MFC-5100C-FM5.5
Assembly
Removing the Protective Yellow Bar
1 Lift the cover toward the back.
2 Pull the protective yellow bar out of the machine.
Caution
Do not throw away the protective yellow bar. You will need it for future
transportation.
3 Close the top cover, and then close the control panel cover.
Scanner Cover
Protective
Yellow Bar
Protective
Yellow Bar
