ASSEMBLY AND CONNECTIONS
2 - 13
BHL-FB-MFC-5100C-FM5.5
Connecting the MFC
Connecting an External Telephone
Although your MFC does not have a handset, you can connect a separate
telephone (or telephone answering device) directly to your MFC.
Connect the modular plug on the telephone’s line cord to the jack labeled EXT.
on the left side of the MFC.
Whenever this phone (or TAD) is in use, the LCD shows TELEPHONE.
Connecting an External Telephone Answering
Device (TAD)
Sequence
You may choose to connect an answering system. However, when you have an
external TAD on the same telephone line as the MFC, the TAD answers all calls
and the MFC “listens” for fax calling (CNG) tones. If it hears them, the MFC
takes over the call and receives the fax. If it doesn’t hear CNG tones, the MFC
lets the TAD continue playing your outgoing message so your caller can leave
you a voice message.
The TAD must answer within five rings (the recommended setting is two rings). The
MFC cannot hear CNG tones until the TAD has answered the call, and with five
rings there are only 8 to 10 seconds of CNG tones left for the fax “handshake.” Make
sure you carefully follow the instructions in this manual for recording your outgoing
message. We do not recommend using the toll saver feature on your external
answering machine if it exceeds five rings.
Note
If INK EMPTY shows on the LCD after you install the ink cartridges, check
to make sure the ink cartridges are installed correctly.
Note
If you do not receive all your faxes, you must reset the setting on your external TAD
to four rings.
If You Subscribe to your Telephone Company’s Distinctive Ring Service:
You may connect an external TAD to a separate wall jack only if you subscribe
to your telephone company’s Distinctive Ring service, have registered the
distinctive ring pattern on your MFC, use that number as a fax number and set
your machine’s Receive mode to MANUAL. The recommended setting is
three or four rings on the external TAD when you have the telephone
company’s Distinctive Ring Service.
If You Do Not Subscribe to Distinctive Ring Service:
You must plug your TAD into the EXT. jack of your MFC. If your TAD is
plugged into a wall jack, both your machine and the TAD will try to control the
phone line. (See illustration, page 2-14.)
