3-15
Confidential
7 Low-voltage Power Supply PCB ASSY
Front
Front
“a”
“b”
“c”
“a”
“b”
“c”
Low-voltage power supply cover
Low-voltage power supply PCB ASSY
Lower cable rack
Hook
CN24
CN23
CN5
Engine PCB ASSY
Main PCB ASSY
Lower cable rack
Top drive ASSY
Paper eject sensor PCB ASSY
