Brother MFC-9465CDN Service Manual

5-22
Confidential
1.4.10 Operational check of sensors (Function code 32)
<Function>
This function allows you to check each of the sensors.
<Operating procedure>
(1) Press the 3 and 2 buttons in this order in the initial state of the maintenance mode.
(2) The machine beeps 1,100 Hz and 400 Hz tones cyclically through the following volumes
for testing the speaker. To stop beeping, press the OK button.
Fig. 5-13
If the sensing status are as listed below, the LCD will show "C1C2L2T2**" when paper
tray 2 is installed. "C1********" appears on the LCD when paper tray 2 is not installed.
Press the Start/Black button to check the next item.
Given below is the relationship between the LCD indication, sensor name and sensor
state.
LCD Sensors Sensing status (OK/NG)
C1 T1 paper edge sensor Paper tray 1 not installed/installed
C2 T2 paper edge sensor Paper tray 2 not installed/installed
L2 T2 plate-up detection sensor Plate down/Plate up
T2 T2 connector Paper tray 2 installed/not installed
MP MP paper empty sensor MP tray paper not detected/detected
MR MP registration front sensor MP tray paper not detected/detected
CV Front cover sensor Front cover closed/open
RC Back cover sensor Back cover closed/open
RM Registration front sensor Paper not detected/detected
RA Registration rear sensor Paper not detected/detected
PO Paper eject sensor Paper not detected/detected
FW Waste toner sensor OFF/ON
NK New toner sensor Black OFF/ON
NY New toner sensor Yellow OFF/ON
NM New toner sensor Magenta OFF/ON
NC New toner sensor Cyan OFF/ON
KC Toner sensor Black Toner (K) detected/not detected
YC Toner sensor Yellow Toner (Y) detected/not detected
MC Toner sensor Magenta Toner (M) detected/not detected
CC Toner sensor Cyan Toner (C) detected/not detected
Note:
- The "--" appears on the LCD if there is no display.
- The "**" appears on the LCD if the parts are not installed or there is no item.
OFF
400 Hz
Low Medium High
1,100 Hz
High Medium Low
OFF

Brother MFC-9465CDN Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Duplex printing mode	Auto
Time to first page (color, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	7 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Page description languages	PCL 6, PostScript 3
Scan to	E-mail, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	1.99 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	19 s
Copy speed (black, normal quality, A4)	24 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2.5 sec/page
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Display	LCD
Product color	Black, Ivory
Display diagonal	2.76 \
Market positioning	Business
Display number of lines	5 lines
Display number of characters	16
Internal memory	256 MB
Processor family	Star Sapphire
Maximum internal memory	512 MB
Sound power level (standby)	33 dB
Sound pressure level (printing)	57 dB
Paper tray media types	Bond paper, Glossy paper, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	70 W
Power consumption (PowerSave)	1.7 W
Power consumption (average operating)	570 W
Dimensions (WxDxH)	410 x 503 x 492 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Package weight	32000 g
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	503 mm
Width	410 mm
Height	492 mm
