1.3 List of Maintenance-mode Functions
*The functions shaded in the table above are user-accessible.
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.4.1 (5-4)
05 Printout of scanning compensation data 1.4.2 (5-5)
06 Placement of document scanner unit in position for
transportation
1.4.3 (5-11)
08 ADF performance test 1.4.4 (5-11)
09 Monochrome image quality test pattern 1.4.5 (5-12)
10 Worker switch (WSW) setting 1.4.6 [1] (5-13)
11 Printout of worker switch data 1.4.6 [2] (5-16)
12 Operation check of LCD 1.4.7 (5-17)
13 Operational check of control panel button 1.4.8 (5-19)
25 Software version check 1.4.9 (5-21)
32 Operational check of sensors 1.4.10 (5-22)
33 LAN connection status display 1.4.11 (5-26)
43 PC print function 1.4.12 (5-27)
45 Not-disclosed-to-users functions 1.4.13 (5-30)
52 EEPROM customizing
(User-accessible: Non Touch panel model only)
1.4.14 (5-35)
53 Received data transfer function 1.4.15 (5-36)
54 Fine adjustment of scan start/end positions 1.4.16 (5-38)
55 Acquisition of white level data 1.4.17 (5-40)
61 Adjustment of touch panel 1.4.18 (5-41)
66 Adjustment of inter-color position alignment 1.4.19 (5-42)
67 Continuous print test 1.4.20 (5-46)
68 Laser unit test pattern print 1.4.21 (5-49)
69 Frame pattern print (One-sided) 1.4.22 (5-50)
70 Frame pattern print (Two-sided) 1.4.23 (5-51)
71 Color test pattern 1.4.24 (5-52)
72 Sensitivity adjustment of density sensor 1.4.25 (5-54)
74 Setting by country 1.4.26 (5-55)
77 Printout of maintenance information 1.4.27 (5-57)
78 Operational check of fans 1.4.28 (5-58)
80 Display of machine history (log) 1.4.29 (5-59)
82 Error code indication 1.4.30 (5-64)
83 Developing bias voltage correction 1.4.31 (5-65)
87 Sending communication error list 1.4.32 (5-66)
88 Counter reset after replacing the fuser unit and paper
feeding kit
1.4.33 (5-66)
91 EEPROM parameter initialization 1.4.1 (5-4)
99 Exit from the maintenance mode 1.4.34 (5-67)
