Brother P-touch E550W Quick Setup Guide

 GETTING STARTED
ENGLISH
27
Power Supply
Alkaline/Ni-MH Battery
After making sure that the power is off, remove the rear cover
on the back of the P-touch. If the batteries are already in the
P-touch, remove them.
Insert six new AA-size alkaline batteries (LR6), or fully
charged Ni-MH rechargeable batteries (HR6). Make sure
that the positive (+) and negative (-) ends of the batteries
match the positive (+) and negative (-) marks inside the
battery compartment.
Users of alkaline batteries
23
Users of Ni-MH rechargeable batteries
Attach the rear cover by inserting the three hooks at the
bottom into the slots on the P-touch, then pushing down
firmly until it snaps into place.
Make sure that the power is turned off when replacing
batteries.
1
Always replace all six batteries at the same time using brand
new ones.
Always replace all six batteries at the same time with fully
charged ones.
Visit us at http://solutions.brother.com/ for the latest
information about recommended batteries.
2
3
• Remove the batteries if you do not intend to use the P-touch for an extended period of time.
• Dispose of the battery at an appropriate collection point, not in the general waste stream.
In addition, be sure to observe all applicable regulations.
• When storing or discarding the battery, wrap it (for example with
cellophane tape), to prevent it from short-circuiting.
(Battery insulation example)
1. Cellophane tape
2. Alkaline or Ni-MH battery
2
1

Brother P-touch E550W Specifications

General

Print Technology	Thermal transfer
Maximum Tape Width	24 mm
Connectivity	Wi-Fi, USB
Display	LCD
Keyboard	QWERTY
Print Resolution	180 dpi
Print Speed	30 mm/sec
Label Width	3.5 mm - 24 mm
Power Source	AC Adapter
Cutter	Automatic
Weight	1.05 kg
