Brother P-touch E550W Quick Setup Guide

GETTING STARTED
30
Feeding Tape
Auto Power-Off Time
Feed & Cut
The Feed & Cut function feeds 24.5 mm of blank tape, and then cuts the tape.
Press the Feed & Cut key.
“Feed & Cut?” will appear on the LCD display.
Using the or key to select the “Feed & Cut” and then press either OK or Enter.
The message “Feeding Tape... Please Wait” appears while the tape is fed, and then the
tape is cut.
Feed Only
This function will advance the tape approximately 24.5 mm, resulting in a blank label sticking
out of the tape cassette. This action is recommended when using Fabric tapes, which should
be cut using scissors.
Setting Value Setting Value
AC Adapter Off Li-ion Battery Off
10min. 10min.
20min. 20min.
30min. 30min.
40min. 40min.
50min. 50min.
1hr. 1hr.
2hr.
4hr.
8hr.
12hr.
• If you connect the AC adapter to the P-touch after you specified “Auto Power Off”, the setting
for “AC Adapter” becomes valid.
• The default value is “1hr.” for the AC Adapter and “30min.” for the Li-ion battery.
Feeding Tape
• Be sure to feed tape to remove any slack in the tape and ink ribbon after inserting the tape
cassette.
• Do not pull the label coming out of the tape exit slot. Doing so will cause the ink ribbon
to be discharged with the tape. The tape may no longer be functional after the ink
ribbon discharges.
• Do not block the tape exit slot during printing or when feeding tape. Doing so will cause the tape
to jam.
1
2
To exit or cancel this function press Esc.

Brother P-touch E550W Specifications

General

Print Technology	Thermal transfer
Maximum Tape Width	24 mm
Connectivity	Wi-Fi, USB
Display	LCD
Keyboard	QWERTY
Print Resolution	180 dpi
Print Speed	30 mm/sec
Label Width	3.5 mm - 24 mm
Power Source	AC Adapter
Cutter	Automatic
Weight	1.05 kg
