Brother QL-800 User Manual

Changing the Label Printer Settings
15
4
4 Select the settings you want to change, and then specify or change the settings in the dialog box.
For more information on the settings dialog boxes, see Device Settings for Windows
®
on page 16.
5 Click [Apply], and then click [Exit...] to apply the settings to the printer.
6 Click Exit.
Important
Use the Printer Setting Tool to configure the printer only when the printer is waiting for the next print job.
The printer may malfunction if you try to configure it while it is handling a job.

Brother QL-800 Specifications

General

Color	Yes
Text alignment	Right, Center, Left
Printing colors	Black, Red
Print technology	Direct thermal
Maximum resolution	300 x 600 DPI
Maximum print height	58 mm
Minimum print length	1000 mm
Maximum printing width	60.96 mm
Maximum label width	62 mm
Maximum label length	1 m
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
PC connection	USB 2.0
Sustainability certificates	ENERGY STAR
Display	-
Product color	Black, Grey
Housing material	Plastic
Cables included	USB
Bundled software	P-touch Editor Lite P-touch Editor 5 P-touch Address Book
Cartridges quantity	2 pc(s)
Tape type	DK
Flash memory	6 MB
Number of fonts	5
Number of styles	8
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1-128, ISBN-2, ISBN-5, ITF-25, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	Raster_P
AC input voltage	220 - 240 V
Package depth	184 mm
Package width	264 mm
Package height	232 mm
Package weight	2090 g
Label memory	99 label(s)
Number of frames	126
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Number of languages	18
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	213 mm
Width	125 mm
Height	142 mm
Weight	1150 g
