213
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON SYSTEM FAULT CODE CHART
10
110
Trim Switch Module Com-
munication Fault
Remote control cannot com-
municate with trim and tilt
switch panel (3, 4, or 5
engines only).
The fault message is sent
from the remote control to the
outboard’s EMM.
None
Trim and tilt switch panel harness
is damaged or not connected to
the remote control.
Trim and tilt switch panel harness
is damaged or not connected to
the switch panel.
Trim and tilt switch panel circuit
failure.
Remote control is programmed
with the wrong part number.
Trim Panel Check (Chart 12)
Remote Control Part Number
Check (Chart 4)
111
ESM Communication Fault
Remote control has detected
a communication fault mes-
sage from the ESM.
The fault message is sent
from the remote control to the
outboard’s EMM.
All gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
30A fuse for the ESM has failed.
The ESM buss cable is damaged
or not connected to the 6-port
hub.
The ESM buss cable extension is
damaged or not connected to the
6-port hub.
6-port hub LED is not ON
6-port hub connection port is
damaged.
ESM instance plug numbers are
duplicated.
ESM Check (Chart 16)
149
Throttle Actuator Sensor
Fault
The ESM has lost the throttle
actuator position sensor sig-
nal.
The fault message is sent
from the ESM to the out-
board’s EMM.
All gear position LED’s flash five
times per second.
All gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
RFI due to excessive spark plug
gap, damaged or worn spark
plugs.
The actuator and the ESM are not
connected.
The actuator and ESM connec-
tors are damaged.
The wiring of the actuator and
ESM connectors are in the wrong
locations.
Throttle actuator position sensor
failed.
Throttle Actuator Sensor
Check (Chart 17)
Fault Code Description LED Indicators
Possible Causes and
Flowchart Reference
