EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON SYSTEM FAULT CODE CHART
ICON System Fault Code Chart
Use this chart and Evinrude Diagnostics software to identify ICON Remote Control System fault codes.
Use the ICON System Troubleshooting Flowcharts to resolve a problem on an ICON Syste m. Refer to
the Evinrude ICON System Troubleshooting Guide.
Fault Code Description LED Indicators
Possible Causes and
Flowchart Reference
107
Remote Control Communi-
cation Error
The outboard’s EMM has not
received a message from the
remote control for more than
1.5 seconds.
The fault message is gener-
ated by the outboard’s EMM.
Gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
Remote control is not powered
ON.
The remote control buss cable is
damaged or not connected.
A remote control buss cable
extension is damaged or not con-
nected.
6-port hub LED is not ON
6-port hub connection port is
damaged.
Remote Control Power Check
(Chart 5)
108
RPM Reduction (S.A.F.E.)
Code 108 always appears
with fault codes 107, 109, 111,
149 and 151.
The fault message is sent
from the remote control to the
outboard’s EMM.
Gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
Remote control not communicat-
ing with ESM.
Remote control lever failure.
ESM not communicating with
remote control.
Throttle actuator sensor failure
Shift actuator sensor failure.
See Evinrude Diagnostics or the
service manual for other S.A.F.E.
fault codes not caused by the
ICON System.
ICON System Fault Check
(Chart 11)
109
Remote Control Lever Fault
The remote control lever
potentiometer resistance is
out of range.
The fault message is sent
from the remote control to the
outboard’s EMM.
Gear position LED’s flash five
times per second.
With the remote control lever in
NEUTRAL, the NEUTRAL LED
of the affected engine continues
to flash five times per second.
Remote control lever potentiome-
ter failure.
If this code is present, replace the
remote control.
