ENGINE MANAGEMENT MODULE (EMM)
INTERNAL SENSORS
INTERNAL SENSORS
Sensor inp uts and inte rnal EMM contro llers are
used to control outboard operation. Use Evinrude
Diagnostics software to troubleshoot the sensors.
Refer to t he EMM Servic e Code Chart at the
back of this manual for a comp lete list of all
engine fault codes.
Internal sensors are NOT serviceable. Re pro-
gramming or replacement ma y be required to
resolve EMM related issues.
EMM Temperature Sensor
Monitors the temperature of the fuel injector driver
circuits.
If the EMM temperature exceeds 176°F (80°C) or
the circuit fails, the EMM:
If EMM temp erature excee ds 212°F (100 °C) or
the circuit fails, the EMM:
IMPORTANT: The outboard will not restart until
the engine cools below 212 °F (100°C) and the
EMM temperatu re returns to normal. Re fer to
SHUTDOWN MODE on p. 63.
If EMM temperature is less tha n -22°F (-30°C) or
the circuit fails, the EMM:
If sensor reads less than -67°F (-55°C) or greater
than 31 1°F (155°C) a senso r circu it fault is
detected and the EMM:
55 V Circuit Sensor
Monitors the EMM’s 55 V alternator circuit.
If system voltage exceeds 57 volts, the EMM:
If system volt age is less than 45 V between 5 00
and 1000 RPM, or is le ss than 5 2 V above 10 00
RPM, the EMM:
12 V Circuit Sensor
Monitors the EMM’s 12 V alternator circuit.
If battery voltage exceeds 15.5 volts, the EMM:
If battery volt age is less tha n 12 V below 20 00
RPM, or is less than 12.5 V above 2000 RPM, the
EMM:
Activates S.A.F.E.
Stores service code 25
EMM LED 4: ON (Running)
Engine Monitor TEMP display: ON
Activates SHUTDOWN
Stores service code 29
EMM LED 4: FLASHING
Engine Monitor TEMP display: FLASHING
Stores service code 24
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
Stores service code 23
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
Activates S.A.F.E.
Stores service code 18
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
Activates S.A.F.E.
Stores service code 17
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
Stores service code 27
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
Stores service code 26
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
