TRIM AND TILT
TRIM AND TILT SERVICE
14
Clean any thread -locking ma terial from the
threads on the inside of the nu t. Spray threads of
with Locquic Primer and let dry . App ly a small
amount of Nut Lock to the threads. Slide the
washer o ver the th reads and inst all the n ut.
Tighten to a torqu e of 58 t o 87 f t. lbs. (79 to 118
N·m).
To en sure that the tilt piston ha s b een p roperly
assembled and the impact relief balls are properly
seated, apply Power Trim/Tilt & Steering Fluid on
top of the tilt piston. Fluid should not leak p ast the
impact relief b alls while seated. If fluid does leak,
disassemble the piston assembly and inspect the
relief ball seats. Set the tilt rod assembly aside.
Trim Rod Removal
Unscrew trim cylin der end caps using Trim Cylin-
der End Cap Remove r/Installer, P/N 43 6710, or
Universal S panner W rench, P/N 912084, and a
breaker bar. Small pins must be used in the span-
ner wrench.
Slide t he cap s to th e e nd o f the rods. Drain th e
fluid from the top of the pistons.
Slowly pu ll each piston out wit h a ra g wrappe d
around the rod and the top of the cylinder.
41783
41828
41829
41837
41838
