Technical data and installation
SMART CLEARER - 2.1 -
2
2 2
2 –
––
– TECHNICAL DATA AND INSTALLATION
TECHNICAL DATA AND INSTALLATION TECHNICAL DATA AND INSTALLATION
TECHNICAL DATA AND INSTALLATION
Technical Features
SMART CLEARER Terminal
Power supply voltage 24 Vdc ± 10%
Maximum Absorption 100 mA
Dimensions 135 x 95 x 40 mm
Temperature range 10° - 60 °C
LCD graphic Display 80 x 40 mm
Integrated Touch-pad 5 membrane buttons with integrated red LED
Protection 2 fuses 5 x 20 – 1A
ISSC.. Sensors
Power supply voltage 12 .. 24 Vdc ± 20%
Absorption 30 mA (max 50 mA)
ENABLE input logic Programmable (NO - NC)
STOP output NPN open collector
STOP output logic Programmable (NO - NC) (cont. – pulse, 2sec.)
"Auto-calibration" function Auto-calibration of sensor
STOP output protection Protection against over-voltages and short-circuits
STOP output max current 200 mA continuous; 500 mA peak
Activation delay Programmable from 1 to 250 sec
Signaling With integrated LED
Dimensions 15 x 15 x 36,5
Temperature range 10° - 50 °C
Installation
The installation of the SMART CLEARER system depends on the type of
application and on the number of sensors to be connected. When the number of
sensors is limited, it is possible to connect them directly to the SMART terminal,
otherwise it is necessary to use a stabilized power supply PSU 10A. This is
capable of supplying up to 8 independent backbone lines to which it is possible to
connect several sensor chains (up to a maximum of 100 sensors). The number of
sensors may be extended to 200, using two PSU 10A power supply.
