Congratulations for choosing a BTSR product.
With our SMART
CLEARER yarn control system, you got an innovative, unique
solution, able to offer you multiple advantages concerning quality control of your
production. SMART
CLEARER has been designed for application on textile
machines dedicated to the preparation of yarn (cone winder, doubling, twisting
frame, interlacing machines, etc.), which during the entire productive cycle utilise
a specified number of yarns on several sections, in continuous mode. In this kind of
application it is necessary to immediately detect a possible technical fault along the
yarn, stop the position where the fault occurred and signal the fault. The task of the
ISSC.. series BTSR sensors is to detect these technical failures.
How to use this manual
This Operation Manual is divided into 4 Chapters and 2 Appendices.
Chapter 1 – Overview describes the main features, components and how the
system works.
Chapter 2 – Technical Data and Installation gives the necessary instructions to
install the system correctly.
Chapter 3 – Operation gives a detailed description of the necessary operations to
setup and program the system according to the application needs.
Chapter 4 – Troubleshooting and Maintenance provides a quick guide to solving
the main technical faults of the system.
Appendix A – Quick reference summarises the sequence of operations that staff
who have had sufficient experience in handling the system, have to carry out in
order to setup and program the system.
Appendix B – Electrical Connections include a connection diagram showing the
use of the SMART CLEARER system and ISSC.. sensors in a general purpose
application environment.
Symbols used
Highlights notes, warnings and subjects to which the attention of the reader
should be directed.
Indicates a particularly sensitive situation which could have an effect
on the safety or proper operation of the system.
ISSC.. The ISSC.. BTSR sensor family includes some variants indicated by the
letters following the ISSC term. (e.g. ISSC-A). Within this manual we will
always use the generic term ISSC..
While scrolling through features that can be activated from the SETUP and
WORK menus, this symbol indicates the procedure that describes the
specific feature. The same symbol is reported at the beginning of the page,
which describes in details the function itself.
