Bucher Municipal
V Range
Routine Maintenance
129
V50 • V65 • V80 Operator’s Guide
Lower WSB for Replacement/Adjustment
To lower the nozzle first, turn on the ignition and then turn off the axillary engine. All nozzles
will now lower to the ground.
Removal
With the brush in the lowered position remove the 3 bolts (A) from the end plate (B) opposite
the hydraulic motor.
Withdraw the plate assembly and remove the brush.
Refitting
Slide new brush under the wide sewwp brush carriage. Engage the core on the motor drive
dog. Refit the end plate assembly turning it if necessary to engage the bearing drive dog.
*Line the end plate up with the carriage and refit the 3 securing bolts (A).
(*) A location hole (C) is provided for a tapered bar to locate and hold the end plate
assembly in place, while bolts (A) are being located.
Wide Sweep Brush Stock Replacement
Wide Sweep Brush Adjustment
The Wide Sweep Brush balance control system has been designed so as not to require
any regular adjustment by the operator.
The system uses electronic proportional regulators which are factory set to optimise the
sweeping performance and life of the brush.
Should the brush show signs of wearing conically then the adjustment should be checked
it is recommended that this is carried out by trained personnel. The adjustment procedure
can be found in chapter 5 of this guide.
It is recommended that the adjustment is checked following brush replacement.
CAUTION
The use of needle stick gloves is recommended when working with this equipment.
