Bucher Municipal
V Range
Controls
37
V50 • V65 • V80 Operator’s Guide
DOOR CONTROLLER
*Powascrub
ON / OFF
Increases Wide Sweep Brush ground pressure to preset level.
Gutter sprays
ON / OFF
Eco Mode/Eco Override/Boost (Vt)
ON / OFF
Eco Mode: Allows engine speed to be increased to 1400rpm.
Eco Override: Allows engine speed to be increased to 1750/1850 rpm.
This mid speed will be different depending on low or high power engine.
Boost Mode: Allows engine speed to be increased to 2000rpm.
*Powathrust
ON / OFF
Increases Channel Brush ground pressure.
Nozzle
Water sprays ON / OFF
Raise / Lower Intake flaps open automatically.
Front Facing only - Lower Nozzle allows Channel Brush (B) to be lowered.
Raising Nozzle automatically stows Channel Brush (B).
Eco Mode/Eco Override/Boost when sweeping (Vh/Vm)
ON / OFF
Eco Mode: Allows fan speed to be operated at the ideal level for regular
sweeping.
Eco Override: Allows fan speed to be increased for heavy sweeping conditions.
Boost Mode: Allows fan speed to be increased to maximum. Activates fan only
when using Wanderhose.
Channel Brush
Water sprays ON / OFF
Raise / Lower
Front Facing only - Active once Nozzle is lowered.
Wide Sweep Brush
Water sprays ON / OFF
Raise / Lower / Slew to side selected.
Holding switch for 3 seconds can be used to reverse WSB slew position if user
preference is selected.
Vt/Vh/Vm
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(I)
(J)
Channel Brush Speed Control
+ Pulse/Hold Increases brush speed.
- Pulse/Hold Decreases brush speed.
Engine Speed Control
+ Pulse/Hold Increases engine speed
- Pulse/Hold Decreases engine speed
Pause
ON / OFF
Suspends active sweep functions and stows equipment
Re-activates equipment to the previous settings
Symbol Description
(G)
(K)
(L)
Coarse dirt pick-up flap
OPEN / SHUT
Suction tube intake raise/lower
LIFT / LOWER
Alternative buttons when optional Forward Facing Sweepgear is fitted
