Bucher V65m - Multifunction Wireless Pendant; Powasave Regulator

Bucher Municipal
V Range
Controls
43
V50 • V65 • V80 Operator’s Guide
MULTIFUNCTION WIRELESS PENDANT
Opens rear door
Closes rear door
Raises body
Lowers body
Stows body prop when body is raised and not resting on it
Green safety switch must be pressed to enable all discharge functions
Green LED On - Pendant transmitting signal to receiver.
Red LED On - Battery charge low.
Function A - Load Discharge
Function B - WSB Balance
Activating Soft Key F3 on JVM: Opens Main Menu 4.00
• Rotate the central encoder to highlight menu 10, Wide Sweep Brush Balance.
• Press the encoder to select.
• Follow the on screen prompts. (See Chapter 7 JVM)
Description
Symbol
(A)
(B) + (D)
(C) + (D)
(F) + (D)
(E) + (D)
(G) + (D)
(D)
* Powasave (I); - In cab regulator (two on Dual Sweep) sets a Light Sweep to maximise brush life.
With the brush working, turn the regulator Anti-clockwise to set the ground pressure to its
maximum, now turn Clockwise to reduce the pressure to the required setting.
POWASAVE REGULATOR
(D) + (F1) + Function
NOTICE: To connect a replacement wireless pendent to the JVM system, please contact Bucher
Municipal Technical Support.
(H)
Wireless pendant ON-OFF switch.
NOTICE: When opening the rear door from closed position using the auxiliary engine (Vt) or when
in Hydrodrive (Vh), the prime side intake flap will open momentarily to vent the suction and reduce
the pressure on the rear door.
Temporarily cancels audible safety warning (bleep).
(JVM user preference menu option)
