Bucher Municipal
V Range
Operation
57
V50 • V65 • V80 Operator’s Guide
Vm
Start chassis engine
The JVM will power up.
Ensure the low air pressure warning lamp and buzzer are off.
Switch ignition ‘On’
Activate using button (A) JVM displays ‘Ignition page’
Water Tank Level - Engine RPM - Fuel Tank Level (optional)
Selecting Work Mode
Activate button (B) to select the Work Mode.
COMMENCE SWEEPING
Selecting the hand of sweep
Activate button to switch between single (left or right) or Simultaneous sweep.
Dual sweep machines without Simultaneous sweep option.
The equipment can only be set to operate on either the Left or Right hand side.
The selected hand of sweep is indicated by the illumination of the switch located on the centre
console. To change the hand of sweep select the side that is not illuminated.
Dual sweep machines featuring Simultaneous sweeping option.
For Single Sweep Operation: The equipment can be set to operate on either side, Left or Right
hand, to change the hand of sweep first select the side that is not illuminated before de-selecting
the other side.
For Simultaneous Sweep Operation:
Select the side that is not illuminated, both sides will now be illuminated indicating the Simultaneous
sweep mode.
Activating the Sweeping Equipment using the Door Controller:
Pressing the corresponding symbol activates the equipment to its sweeping position, the symbol is
displayed on the JVM. The top of the switch activates the corresponding water jets.
Gutter Sprays.
Pressing the switch activates the corresponding gutter spray.
Commence Sweeping:
Select the lowest gear to give a road speed between 2-8 mph (2 to 12 km/h).
Always use the slowest brush and engine speeds consistent with satisfactory cleaning.
Normal engine operating speeds between 1200 - 1500 rev/min.
Eco Mode (C)
Enables the fan speed to be operated at the ideal level for regular sweeping whilst maximising fuel
economy and minimising noise and emissions.
Eco Mode Override (D)
Enables the fan speed to be increased for heavy sweeping conditions.
Boost Mode (Option) (E)
Enables the fan speed to be increased to maximum when particularly arduous sweeping conditions
are encountered.
VEHICLE START UP
