Bucher Municipal
V Range
73
Optional Equipment
V50 • V65 • V80 Operator’s Guide
MICROTRAP
VARAGAP NOZZLE
Allows the lateral position of the channel brush to be altered whilst sweeping. Operating the
Multifunctional joystick moves the channel brush in/out from its nominal working position.
The Maxigap cylinder is replaced by a version offering a variable aperture for the nozzle. Moving the
lever up closes the nozzle, moving the lever down opens the nozzle. The length of time the lever
is held dictates the nozzle gap.
VARIABRUSH
Standard feature: Operating the Joystick left/right positions Prime-side Channel Brush fully In or
fully Out
Standard feature: Operating the Joystick left/right together with the push button positions the non
Prime-side Channel Brush fully In or fully Out
Optional Variabrush feature: Operating the Joystick left/right together with the push button
positions the non Prime-side Channel Brush as required
Operation
The standard channel brush water switch activates the PM10 jets (A) and (B).
The standard channel brush jets are activated in conjunction with the gutter spray switch.
Check daily that all additional micro water jets are functioning not blocked.
Taps are provided on spraybars (B) and (C) so that the operator has some adjustment if required.
CAUTION
Do not use this option at temperatures below 5°C.
Optional Variabrush feature: Operating the Joystick left/right positions Prime-side Channel Brush
as required
