Bucher Municipal
V Range
Controls
39
V50 • V65 • V80 Operator’s Guide
MULTIFUNCTIONAL JOYSTICK CONTROLS
Operating the Joystick up closes the Nozzle
Prime-side Channel Brush with Standard feature:
Operating the Joystick left/right positions Prime-side Channel Brush fully In or fully Out.
Secondary-side Channel Brush with Standard feature:
Operating the Joystick left/right together with the push button positions the Secondary-side
Channel Brush fully In or Out
Secondary-side Rotatilt Moving the Joystick left/right together with both the button on the top and
the end moves the Secondary-side Rotatilt
Prime-side Rotatilt
Moving the Joystick left/right together with the button on the top Moves the Prime-side Rotatilt
Function A - Maxigap/Varagap
Function B1 - Prime Side Channel Brush
Function C1 - Prime Side Rotatilt
Prime-side Channel Brush with Optional Variabrush feature:
Operating the Joystick left/right positions Prime-side Channel Brush as required
Secondary-side Channel with Optional Variabrush feature:
Operating the Joystick left/right together with the push button positions the Secondary-side
Channel Brush as required
Operating the Joystick down opens the Nozzle
Function B2 - Secondary Side Channel Brush
Function C2 - Secondary Side Rotatilt
