Bucher V65m - Multifunctional Joystick Controls - Front Facing Sweepgear

Bucher Municipal
V Range
Controls
41
V50 • V65 • V80 Operator’s Guide
MULTIFUNCTIONAL JOYSTICK CONTROLS
Operating the Joystick up closes the Nozzle down.
Operating the Joystick left/right positions Nozzle/Channel Brush fully in or out.
First move retracts / extends Nozzle.
Second move retracts / extends Channel Brush.
Channel Brush retract and Nozzle retract are both independent options that will only function if fitted.
The order of the function can be reversed if user preference is selected.
Note: If the Wide Sweep Brush only is selected, the joystick can be used to slew the brush left/
centre/right if user preference is selected.
Operating the Joystick left/right together with the push button positions Nozzle/Channel Brush fully
in or fully out.
First move retracts / extends Nozzle.
Second move retracts / extends Channel Brush.
Channel Brush retract and Nozzle retract are both independent options that will only function if fitted.
The order of the function can be reversed if user preference is selected.
If Simultaneous Sweep is fitted and selected then the nozzle retract feature will be automatically
locked in to ensure full width sweep. Channel Brush retract will stay active.
Pressing the button once will fully extend the telescopic Sweepgear, both Channel Brushes and
Nozzles.
Second press will retract the telescopic Nozzle.
Alternatively, first move of the joystick will retract the telescopic Nozzle.
Second move retracts Channel Brush (if Channel Brush retract option is fitted).
Function A - Maxigap/Varagap
Function B1 - Prime Side Sweepgear retract / extend (optional)
Function C1 - Prime Side Telescopic Nozzle (optional feature)
Operating the Joystick down tilts the Nozzle open.
Function B2 - Secondary Side Sweepgear retract / extend (optional)
