Bucher Municipal
V Range
Routine Maintenance
133
V50 • V65 • V80 Operator’s Guide
Forward Facing Sweepgear - Overview of dimensions
CAUTION
The use of needle stick gloves is recommended when working with this equipment.
Ensure the auxiliary engine is not running and isolated before brush adjustment or
replacement is attempted.
Overview of dimensions
Drawing dimensions: millimetres and angles in degrees
(A) Sweep pattern dimensions for roller brush
(B) Distance between suction tube intake and roller brush
(C) Slight tilt angle of suction tube intake
(D) Outer suction intake position
(E) Sweep pattern dimensions, channel brush
