Bucher Municipal
V Range
Routine Maintenance
137
V50 • V65 • V80 Operator’s Guide
Forward Facing Sweepgear - Wide Sweep Brush Stock Replacement
CAUTION
The use of needle stick gloves is recommended when working with this equipment.
Roller Brush settings
(1) Sweep pattern dimensions of the roller brush to ensure correct brush ground
pressure. Uniform sweep pattern along the entire length of the brush.
(1a) Sweep pattern adjuster screw
(2) Swivelling angle
(2a) Swivelling angle adjuster screw
Gap dimensions on guide aprons
Dimensions in millimetres.
Only set and adjust with the vehicle on a level road surface.
(A) Rear of suction tube intake, tilted
(B) Rear of suction tube intake
(C) Side of suction tube intake
(D) Front of suction tube intake
(E) Outer side of suction tube intake
(F) Strip brush of suction intake (on ground)
(G) Channel brush (on ground)
(H) Side of roller brush (on ground)
(I) Roller brush
