Bucher Municipal
V Range
Routine Maintenance
149
V50 • V65 • V80 Operator’s Guide
Pneumatic Filter Regulator Unit
The filter regulator unit comprises an isolation tap and pressure regulator.
The air is isolated and drained by turning the gate valve on the unit.
The air filter features an automatic drain.
Hydraulic Reservoir
Checking Oil Level
Raise the body and engage the body prop (A) in its highest position.
The bottom of the level indicator (B) should not be higher than the Maximum line as
shown on the gauge.
It is important that the correct level is maintained as under filling can adversely affect the
heat dissipation rate of the oil, whilst over filling can cause oil to overflow when the body is
lowered. The recommended oil is shown in the lubrication chart at the end of this chapter.
Vt - Twin Engine
Vh/Vm - Single Engine
Hydraulic Reservoir
Checking Oil Level
Raise the body and engage the body prop (A) in its highest position. The level (B) should
be 10mm above the lower red line (C) on the gauge. It is important that the correct level is
maintained as under filling can adversely affect the heat dissipation rate of the oil, whilst
over filling can cause oil to overflow when the body is lowered. The recommended oil is
shown in the lubrication chart at the end of this chapter.
