Bucher V65m - Lubrication Diagrams (Vh - Single Engine)

Bucher Municipal
V Range
Routine Maintenance
157
V50 • V65 • V80 Operator’s Guide
Approved Lubricants
Capacity ISO Oil Grade
Bucher Municipal
Part No.
Fuchs /
(**)
Klüber
(A) Hydraulic System 75L ISO 6743-4 HV 94-12
Renolin
B46 HVI
(B) Gearbox 7.5L API GL-4 / GL-5 94-67
Titan Cytrac
HSY 75W-90
(C) Supawash Pump 0.37L API GL-4 / GL-5 94-67
Titan Cytrac
HSY 75W-90
(D) Fluid Flywheel *
(E) Engine *
(F) Drive Splines - - 94-24
Klüberpaste
46 MR 401**
(G) Antifreeze *
(H) Chassis PAS - Auto Gearbox
See Chassis
Handbook
- - -
Grease Points - 94-69 Renolit EP2
Auto-Lube - - 94-69 Renolit EP2
Battery Terminals - - -
Petroleum
Jelly
The above oils are those approved by Bucher Municipal.
Other manufacturer’s oils must be of equivalent grade.
(1) Water pump.
(2) Channel brush - (i) Grease when
renewing brush stock.
(3) Wide sweep brush - (i) Grease when
renewing brush stock.
(4) Supawash hose reel.
(5) Drive Splines - lubricate during assembly.
(6) Wanderhose - (i) Rotate boom to
distribute grease around bearing.
(7) Rear door.
(8) Hopper tip pivot pin.
(9) Nozzle wheel.
(10) Body raise cylinder.
(*) Not applicable
LUBRICATION DIAGRAMS
Refer to Maintenance Schedules for lubrication intervals
Vh - Single Engine
Item Description Item Description
WARNING:
Ensure the machine is standing on firm, level ground and there are no obstructions above or
to the rear before raising the body.
Ensure the safety prop is engaged at all times when working under the body.
