5 | Installation BÜCHI Labortechnik AG
20/65 Operation Manual Vacuum Pump V-600
5.2 Installation site
IMPORTANT
Risk of property damage from falling equipment (e.g. in an earthquake)
u Secure the Vacuum Pump against falling by means of the lashing eye on the rear
of the device, see Chapter3.2.2 "Rear view", page12.
The installation site must meet the following requirements:
Firm and level surface: at least 330 mm x 330 mm (W x D)
Height: at least 300 mm
Set up inside a fume hood or
feed the pump outlet into the fume hood
Sufficient clearance on all sides of the device (approx. 10 cm) in order to ensure air
circulation
Clear air outlet at the rear (ventilation slots must be kept clear)
The V-600 is intended for use in laboratory environments. See Chapter3.4.2 "Ambi-
ent conditions", page17.
