Buderus Logamatic EMS RC35 Installation And Service Instructions

Commissioning
Logamatic EMS RC35 programming unit - Subject to technical modifications
20
5
5.3 Quick commissioning (menu quick operation)
B Press to open menu quick operation.
SHORTCUT\ Menu item
Input
range
Factory
setting Other information
BASIC SETUP Which language should
be used?
English, ... Francais
HYDR. SEP. Have you installed a
module for the
hydraulic separator?
yes, no no In conjunction with
MCM10 this setting is
automatically set to “yes”;
the mask is hidden.
1)2)
Is a sensor for a low
loss header
connected?
no,
on the
boiler,
on the low
loss header
module
no When a low loss header
is used, connect the
temperature sensor to the
low loss header module.
3)
SYSTEM Is heating circuit 1
installed (unmixed
heating circuit)?
yes, no yes
NO. OF MIXERS How many mixed
heating circuits are
installed?
0 to 3 0 Set the address at the
rotary coding switch on
the mixer module (factory
setting HC2).
1)
HEATING CIRCUIT
1
(and other heating
circuits)
Which operating unit is
assigned to heating
circuit 1?
RC2x/
RC20/RF,
RC35,
none
RC35 Assigning programming
units to heating circuits
(Æ page 31). General
heating circuit data
(Æ page 27).
Set up any other heating
circuits as per heating
circuit 1.
How should heating
circuit 1 be controlled?
outside
temp.
contr.,
room temp.
controlled
outside
temp.
contr.
Which heating system
does heating circuit 1
have?
radiator,
convector,
floor
radiator Heating curve
(Æ page 32)
Tab. 8 Quick operation menu navigator
SERVICE MENU
B quick operation
settings
diagnosis
servicing
