Buderus Logamatic EMS RC35 Installation And Service Instructions

Logamatic EMS RC35 programming unit - Subject to technical modifications
45
Diagnosis
7
7.4 Heating curve
With the htg. charact. curve you can graphically display the heating curves of individual heating
circuits.
B If the system comprises several heating circuits:
Turn rotary selector to display the heating curve of the next
heating circuit.
7.5 Versions
You can use the INFO\VERSIONS menu to view the software versions for heating system
components.
B If the information cannot be shown in one display:
Turn rotary selector to scroll to the next display.
90
DIAG.\CHAR. CURVE HC2
21
targ. flow tmp. 57°C
INFO\VERSIONS
RC35 1.02
UBA1.5 1.21
