Buderus Logamatic EMS RC35 Installation And Service Instructions

Product information
Logamatic EMS RC35 programming unit - Subject to technical modifications
8
2
2.4 Specification
Temperature sensor characteristics
When measuring temperature sensors, observe the following requirements:
• Isolate the system before measuring.
• Measure the resistance at the cable ends.
• The resistances represent mean values and are subject to tolerances.
Unit RC35
Power supply via BUS system V 16 V DC
Power consumption W 0.3
Power consumption with backlighting W 0.6
Dimensions (width/height/depth) mm 150/90/32
Weight g 233
Operating temperature °C 0 to +50
Storage temperature °C 0 to +70
Relative humidity % 0 to 90
CE designation
Tab. 2 Specification - RC35 programming unit
Outside temperature sensor
Flow temperature sensor
DHW temperature sensor
°C k Ω °C k Ω °C k Ω
– 20 96.358 10 19.872 60 2.490
– 15 72.510 16 15.699 65 2.084
– 10 55.054 20 12.488 70 1.753
– 5 42.162 25 10.001 75 1.481
0 32.556 30 8.060 80 1.256
5 25.339 35 6.535 85 1.070
10 19.872 40 5.331 90 0.915
15 15.699 45 4.372 95 0.786
20 12.488 50 3.606 100 0.677
25 10.001 55 2.989
30 8.060
Tab. 3 Resistances of the temperature sensors, for EMS only
