Logamatic EMS RC35 programming unit - Subject to technical modifications
43
Diagnosis
7
7.2 Monitor value
You can use the monitor value menu to view the set and actual values for the heating system. The
set value will be displayed first and then the actual value. The values displayed for monitoring
purposes vary depending on the system installed.
Observe the information which appears on the display when you switch to menus or
enter settings. Press any key or turn the rotary selector to confirm the information.
No settings will be allowed that might result in damage to the components. This is why
some settings may not be accepted.
If the values to be displayed do not all fit on the screen, they are displayed as a list. The
list can be moved up or down by turning rotary selector.
DIAGNOSIS\MONITOR VALUE Other information
boiler/burner
MCM10/cascade Only in conjunction with MCM10 (instead of “boiler/burner”)
boiler
1)
1) Depending on the boiler used, the monitor values are displayed in individual masks. Call up the monitor
values for the next boiler by turning the rotary selector. Symbol present = the corresponding function is
active. Explanation of symbols Æ Tab. 19, page 44.
Only in conjunction with MCM10 (instead of “boiler/burner”)
Pump module
hydraulic separator
2)
2) Not possible or available on boilers with UBA1.x or DBA.
domestic hot water
heating circuit 1 Values are displayed for additional heating circuits, if these
are installed.
solar
2)
module UM10
2)
For solid fuel boilers; EV2 = external interlock (input)
wireless transm.
2)
FB = strength of the wireless signal
bus users
2)
Tab. 18 Navigator for service menu DIAGNOSIS\MON. VALUE
