2 Technical description
6 720 646 864 (12/2010) – Technical guide Logano GE315, GE515 and GE615
10
2.3.2 Dimensions of the Logano GE515 cast iron boilers
Fig. 7 Dimensions of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE515
(dim. in mm)
1)
Maximum value
2)
Fill the boiler and system via a separate connector on the
return pipe.
3)
See the latest “Prices and technology” catalogue for unit
versions with matching pressure-jet burners for operation
with fuel oil EL and natural gas E and LL.
80
L
K
L
BR
3)
980
1325
586
1556
144
VK
60
L
DN250
RK
585
DN 250
1120
EL
2)
Rp ¾
VK
1315
6 720 644 097-06.1il
270
115
270
1)
Boiler size Unit 240 295 350 400 455 510
Number of boiler sections N – 7 8 9 10 11 12
Length L
L
K
mm
mm
1580
1360
1750
1530
1920
1700
2090
1870
2260
2040
2430
2210
Handling Boiler section
Boiler block
mm
mm
Width 835 / height 1315 / depth 170
Width 835 / height 1315 / length L
K
Burner length With fuel oil L
BR
mm 480 480 645 500 500 645
Combustion chamber Length
Ø
mm
mm
1190
515
1335
515
1505
515
1675
515
1845
515
2015
515
Burner door Depth mm 142 142 142 142 142 142
Boiler flow
Return
ØVK
ØRK
DN
DN
Depending on the order, connection flange is reduced to
DN 100, DN 80 or DN 65
Tab. 2 Dimensions of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE515
(specification
Æ Tab. 4)
