2 Technical description
6 720 646 864 (12/2010) – Technical guide Logano GE315, GE515 and GE615
11
2.3.3 Specification of the Ecostream cast iron boilers Logano GE315
2.3.4 Specification of the Logano GE515 cast iron boilers
Boiler size Unit 105 140 170 200 230
Rated output GE315 kW 105 140 170 200 230
Application range for heat
demand
GE315 kW 86–105 106–140 141–170 171–200 201–230
Rated heat input GE315 kW 92.1–113.5 113.5–151.4 151.0–183.4 183.1–215.1 215.2–247.9
Net weight
1)
1) Add the weight of the burner to the weight of the valve; weight incl. packaging is approx. 6 % to 8 % higher
kg 543 631 719 807 895
Water capacity (approximate) l 143 171 199 227 255
Gas content l 147 181 215 249 263
Flue gas temperature
2)
2) To EN 303; minimum flue gas temperature for chimney calculation to DIN-EN 13384-1 (Æ Tab. 42) (approx. 12 K lower)
Partial load
60 %
Full load
°C
°C
137
162–185
138
154–182
136
161–180
132
158–176
141
168–190
Required draught Pa 0
Pressure drop on hot gas side GE315 mbar 0.28–0.41 0.46–0.79 0.71–1.30 1.34–1.78 1.32–1.77
Permissible flow temperature
3)
3) Safety limit (high limit safety cut-out); maximum flow temperature 18 K lower than safety limit (STB)
Example: safety limit (STB) = 100 °C, maximum flow temperature = 100–18 = 82 °C
°C 120
Permissible operating pressure bar 6
Certificate no. acc. to Pressure
Equipment Directive
– Z-FDK-HUC-00-318-302-02
CE designation – CE-461 AS 255
Tab. 3 Specification of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE315
(dimensions
Æ Fig. 6 and Tab. 1)
Boiler size Unit 240 295 350 400 455 510
Rated output GE515 kW 240 295 350 400 455 510
Application range for heat
demand
GE515 kW 201–240 241–295 296–350 351–400 401–455 456–510
Rated heat input GE515 kW 215.6–259.7 257.8–319.0 316.6–377.1 374.6–429.6 428.4–489.2 488.2–547.8
Net weight
1)
1) Add the weight of the burner to the weight of the valve; weight incl. packaging is approx. 6 % to 8 % higher
kg 1270 1430 1590 1753 1900 2060
Water capacity (approximate) l 258 294 330 366 402 438
Gas content l 421 487 551 616 681 745
Flue gas temperature
2)
2) Figures acc. to EN 303; minimum flue gas temperature for chimney calculation to DIN-EN 13384-1 (Æ Tab. 43) (approx. 12 K lower)
Partial load
60 %
Full load
°C
°C
138
164–183
138
161–183
140
161–177
129
157–171
130
159–172
140
164–174
Required draught Pa 0
Pressure drop on hot gas side GE515 mbar 0.5–0.6 1.0–1.4 1.1–1.6 2.1–2.9 2.5–3.3 2.4–3.1
Permissible flow temperature
3)
3) Safety limit (high limit safety cut-out); maximum flow temperature 18 K lower than safety limit (STB)
Example: safety limit (STB) = 100 °C, maximum flow temperature = 100–18 = 82 °C
°C 120
Permissible operating pressure bar 6
Certificate no. acc. to Pressure
Equipment Directive
– Z-FDK-HUC-00-318-302-04
CE designation – CE-0461 AR 6154
Tab. 4 Specification of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE515
(dimensions
Æ Fig. 7 and Tab. 2)
