2 Technical description
6 720 646 864 (12/2010) – Technical guide Logano GE315, GE515 and GE615
9
2.3 Dimensions and specification of the Ecostream cast iron boilers
2.3.1 Dimensions of the Logano GE315 cast iron boilers
Fig. 6 Dimensions of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE315
(dim. in mm)
1)
Fill the boiler and system via a separate connector on the
return pipe.
2)
See the latest “Prices and technology” catalogue for unit
versions with matching pressure-jet burners for operation
with fuel oil EL and natural gas E and LL.
6 720 644 097-05.1il
L
K
L
BR
2)
880
1035
450
450
1195
56
VK
RK
155
L
938
818
106
RK
DN 180
EL
1)
VK
Rp ¾
Boiler size Unit 105 140 170 200 230
Number of boiler
sections
N –56789
Length L
L
K
mm
mm
1125
970
1285
1130
1445
1290
1605
1450
1765
1610
Handling Boiler section
Boiler block
mm
mm
Width 712 / height 934 / depth 160
Width 712 / height 994 / length L
K
Combustion chamber Length
Ø
mm
mm
790
400
950
400
1110
400
1270
400
1430
400
Burner door Depth mm 125 125 125 125 125
Boiler flow
Return
ØVK
ØRK
DN
DN
Depending on the order, connection flange is DN 65 or
reduced from DN 65 to DN 50 or DN 40
Tab. 1 Dimensions of the Ecostream cast iron boilers and Ecostream cast iron boiler units Logano GE315
(specification
Æ Tab. 3)
