2005 Buell Firebolt: Electrical 7-1
HOME
SPECIFICATIONS 7.1
Table 7-1. Battery Specifications
BATTERY
Size 12 VDC/12 AH/200CCA
Typ e Sealed, AGM
Table 7-2. Spark Plug Specifications
SPARK PLUGS
Size 12 mm
Type 10R12A
Gap 0.035 in. 0.9mm
Torque 11-18 ft-lbs 15-24 Nm
Cable resistance
(front and rear)
1,350-3,465 ohms
Table 7-3. Alternator Specifications
ALTERNATOR
AC voltage output 16-20 VAC per 1000 engine RPM
Stator coil resistance 0.1-0.3 Ohms
Table 7-4. Regulator Specifications
REGULATOR
Voltage output @ 3600 RPM 14.3-14.7 VDC@ 75° F
(24° C)
Amperes @ 3600 RPM 34 Amps
Table 7-5. Ignition Coil Specifications
IGNITION COIL RESISTANCE
Primary winding 0.5-0.7 ohms
Secondary winding 5500-7500 ohms
Table 7-6. Electrical System Specifications
ELECTRICAL SYSTEM AMPERES
Main fuse 30
Ignition fuse 15
Light fuse 15
Accessory fuse 10
Brake/horn/active muffler
fuse (XB12R only)
10
ECM fuse 10
Key switch fuse 15
Cooling fan fuse 10
Table 7-7. Specifications
BULB CHART
BULBS
REQUIRED
WATTS AMPS
PART
NUMBER
Headlights
Bulb (H3) 2 55 4.58 68918-98
Position lamp
(European models only)
230.25 Y0026.02A8
Marker lamps
Tail/Stop Lamp 1 5/21 0.42/1.75 Y0401B.2U
Turn signal lamp (front and rear
1 bulb each)
4 10.0 0.84 Y0042.K
Instruments
Turn signal indicator 1 1.12 0.08 Y0163.02A8
Check engine 1 1.12 0.08 Y0163.02A8
High beam 1 0.7 0.05 Y0162.02A8
Oil indicator 1 1.12 0.08 Y0163.02A8
Neutral 1 1.12 0.08 Y0163.02A8
Backlight
21.12 0.08 Y0163.02A8
10.7 0.05 Y0162.02A8
Low fuel Replace instrument cluster if low fuel warning lamp fails.
