7-2 2005 Buell Firebolt: Electrical
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Battery (+) to starter fastener 60-85
in-lbs
7-10 Nm page 7-34
Battery ground cable and actu-
ator ground wire
48-60
in-lbs
5.4- 6.7 Nm page 7-69
Battery terminal fastener 72-96
in-lbs
8-10.8 Nm page 7-40
Battery terminal fastener 72-96
in-lbs
8-10.8 Nm page 7-40
Battery terminal fasteners 72-96
in-lbs
8-10.8 Nm page 7-33
Battery terminal fasteners 72-96
in-lbs
8-10.8 Nm page 7-66
Fork clamp, upper 17-19 ft-lbs 23-26 Nm LOCTITE 272, page 7-8
Fuse block mounting fasteners 72-96
in-lbs
8.1-10.8 Nm page 7-65
Handlebar control housing
screws (left side)
25-33
in-lbs
3-4 Nm page 7-50
Handlebar control housing
screws (right side)
25-33
in-lbs
3-4 Nm longer screw on bottom, page 7-50
Horn fastener 72-96
in-lbs
8.1-10.8 Nm page 7-59
Ignition switch body fastener 12-36
in-lbs
1.4-4.0 Nm page 7-7
Instrument module fastener 12-36
in-lbs
1.4-4.0 Nm page 7-53
Main battery ground 48-72
in-lbs
5.4-8.1 Nm page 7-66
Main battery ground 48-72
in-lbs
5.4-8.1 Nm page 7-34
Negative battery cable at bat-
tery terminal
72-96
in-lbs
8-11 Nm page 7-69
Neutral indicator switch 36-60
in-lbs
4-6.8 Nm LOCTITE 243 (blue), page 7-61
Relay block mounting fasten-
ers
72-96
in-lbs
8.1-10.8 Nm page 7-65
Rotor mounting fasteners 90-110
in-lbs
10-12 Nm LOCTITE THREADLOCKER 243 (blue), page 7-31
Spark plugs 11-18 ft-lbs 15-24 Nm page 7-1
Stator TORX mounting screws 30-40
in-lbs
3-4 Nm
T- 27 TORX with retaining compound, replace with new
after each removal, page 7-31
Steering head wiring clamp 16-18 ft-lbs 21.7-24.4 Nm page 7-65
Steering stem cap 38-42 ft-lbs 52-57 Nm page 7-8
Steering stem pinch fastener 17-19 ft-lbs 23-26 Nm LOCTITE 272 (red), page 7-8
Turn signal fastener (rear) 25-28
in-lbs
2.8-3.2 Nm page 7-47
Turn signal fasteners (front) 25-28
in-lbs
2.8-3.2 Nm page 7-47
Turn signal flasher fastener 30-40
in-lbs
3.4-4.5 Nm page 7-48
Voltage regulator mounting
screws
48-60
in-lbs
5.4-6.8 Nm use new fasteners, page 7-32
