2005 Buell Firebolt: Chassis 2-3
HOME
Fairing support bracket fas-
tener
16-18 ft-lbs 22-26 Nm page 2-74
Flasher fastener 30-40
in-lbs
3-5 Nm page 2-72
Footpeg mount fasteners,
rider
108-132
in-lbs
12-15 Nm page 2-81
Footpeg mount, passenger 25-28 ft-lbs 34-38 Nm LOCTITE 272, page 2-82
Fork cap 22-30 ft-lbs 30-40 Nm page 2-50
Fork center bolt 22-30 ft-lbs 30-40 Nm page 2-49
Fork clamp, lower 13-15 ft-lbs 18-20 Nm LOCTITE 272, page 2-51
Fork clamp, upper 17-19 ft-lbs 23-26 Nm LOCTITE 272, page 2-54
Fork damper locknut 22-30 ft-lbs 30-40 Nm page 2-49
Front fender fasteners 12-36
in-lbs
1-4 Nm page 2-84
Front isolator bolt 49-51 ft-lbs 66-69 Nm page 2-62
Front isolator bracket mount-
ing fastener
49-51 ft-lbs 66-69 Nm page 2-62
Front isolator snubber, upper 12-36
in-lbs
1-4 Nm page 2-62
Front isolator threaded frame
insert
49-51 ft-lbs 66.4-69.1 Nm LOCTITE 222, page 2-62
Fuse block and relay fasteners 72-96
in-lbs
8-11 Nm page 2-74
Hand lever pivot fastener 60-120
in-lbs
9-14 Nm page 2-28
Handlebar clipon fastener, left 24-26 ft-lbs 33-35 Nm LOCTITE 272, page 2-76
Handlebar clipon fastener,
right
24-26 ft-lbs 33-35 Nm LOCTITE 272, page 2-76
Headlight fasteners 20-25
in-lbs
2.3-2.8 Nm page 2-72
Headlight support bracket
pivot fasteners
72-96
in-lbs
8-11 Nm page 2-73
Heel guard fasteners, passen-
ger
48-72
in-lbs
5-8 Nm page 2-82
Heel guard fasteners, rider 72-96
in-lbs
8-11 Nm page 2-81
License plate fasteners 36-48
in-lbs
4-5 Nm page 2-93
Main battery ground fastener 72-96
in-lbs
8-11 Nm page 2-92
Master cylinder banjo bolt,
front
16-20 ft-lbs 22-27 Nm page 2-31
Master cylinder banjo bolt,
rear
16-20 ft-lbs 22-27 Nm page 2-40
Master cylinder cover fasten-
ers, front
9-13
in-lbs
1.0-1.5 Nm page 2-29
Master cylinder mounting fas-
teners, rear
72-96
in-lbs
8-11 Nm page 2-38
Mirror fasteners 72-96
in-lbs
8-11 Nm page 2-94
Muffler mounting block fas-
tener, rear
32-36 ft-lbs 43-49 Nm page 2-80
Muffler strap fastener, front 108-120
in-lbs
12-14 Nm page 2-80
Muffler strap fastener, rear 48-60
in-lbs
5-7 Nm page 2-80
ITEM TORQUE NOTES
