2-4 2005 Buell Firebolt: Chassis
HOME
Negative battery cable at bat-
tery terminal
72-96 in-lbs 8-11 Nm page 2-70
Oil cooler air scoop 120-144 in-lbs 14-16 Nm page 2-89
Oil drain plug 29-31 ft-lbs 39-42 Nm page 2-60
Oil line fittings 29-31 ft-lbs 39-42 Nm page 2-60
Passenger footpeg mounts 25-28 ft-lbs 34-37 Nm page 2-61
Passenger seat latch 60-96 in-lbs 7-11 Nm page 2-93
Pivot shaft pinch bolt 17-19 ft-lbs 23-26 Nm page 2-61
Ram air scoop 12-36 in-lbs 1-4 Nm page 2-89
Rear fender fastener 12-15 in-lbs 1-1.7 Nm page 2-84
Rear remote master cylinder
reservoir fastener
48-72 in-lbs 11-14 Nm page 2-38
Rotor mounting fasteners,
front
25-27 ft-lbs 34-37 Nm metric, Replace with new, page 2-14
Rotor mounting fasteners, rear 25-27 ft-lbs 34-37 Nm metric, Replace with new, page 2-18
Seat fasteners 12-36 in-lbs 1-4 Nm page 2-95
Shift lever pinch screw 48-60 in-lbs 5.4-6.8 Nm LOCJTITE 272 (red), Page 2-69
Shift pedal flange head bolt 22-24 ft-lbs 30-32.5 Nm page 2-69
Shock mounting fastener,
lower
15-17 ft-lbs 20.3-23 Nm page 2-65
Shock mounting fastener,
upper
49-51 ft-lbs 66-69 Nm page 2-65
Shock reservoir clamp, rear 120-144 in-lbs 14-16 Nm page 2-92
Sidestand bracket fasteners 25-27 ft-lbs 34-37 Nm page 2-98
Sidestand pivot bolt 18-20 ft-lbs 24-27 Nm page 2-98
Sprocket cover fastener 12-36 in-lbs 1-4 Nm page 2-83
Sprocket fasteners 35-37 ft-lbs 48-50 Nm Replace with new, page 2-18
Steering stem cap 38-42 ft-lbs 52-57 Nm page 2-54
Steering stem pinch fastener 17-19 ft-lbs 23-26 Nm LOCTITE 272, page 2-54
Swingarm brace mounting fas-
teners
25-27 ft-lbs 34-37 Nm page 2-61
Swingarm pivot shaft 24-26 ft-lbs 32-35 Nm page 2-61
Switch housing fasteners,
right
25-33 in-lbs 3-4 Nm page 2-66
Tail body work, lower 36-48 in-lbs 4-5 Nm page 2-93
Tail body work, upper 12-36 in-lbs 1-4 Nm page 2-93
Tail frame to frame 21-23 ft-lbs 28-31 Nm LOCTITE 272, page 2-92
Torca clamp 28-30 ft-lbs 38-40.6 Nm page 2-80
Valve stem nut 40-44 in-lbs 4.5-4.9 Nm page 2-22
Wear peg, rider 36-48 in-lbs 4.1-5.4 m page 2-81
ITEM TORQUE NOTES
