2003 Buell P3: Fuel System 4-1
HOME
SPECIFICATIONS 4.1
TORQUE TABLE
Table 4-1. Fuel Tank Capacity
FUEL TANK CAPACITY U.S. METRIC
Total (including reserve) 2.8 gallons 10.6 liters
Reserve 0.55 gallons 2.08 liters
Table 4-2. Carburetor Jet Sizes
CARBURETOR JET SIZES
Main Jet 166
Slow Jet 42
Table 4-3. Carburetor Adjustments
CARBURETOR ADJUSTMENTS
Engine Idle Speed (regular) 1200 RPM
Engine Idle Speed (fast) 2000 RPM
ITEM TORQUE NOTES
Battery cables to terminals 60-96
in-lbs
7-11 Nm Page 4-6
Enrichener stay plate 13-23
in-lbs
2-3 Nm Page 4-15
Fuel cap flange to fuel tank 20-22
in-lbs
2-3 Nm Page 4-12
Fuel tank to T-shaped bracket 72-96
in-lbs
8-11 Nm Page 4-6
Fuel valve to fuel tank 12-14
in-lbs
1-2 Nm Page 4-9
Tank cover to T-shaped bracket 30-36
in-lbs
3-4 Nm Page 4-6
Throttle position sensor 13-23
in-lbs
2-3 Nm Page 4-22
Vent tube fitting 40-60
in-lbs
5-7 Nm Page 4-12
