FRONT FORK OIL 1.14
GENERAL
Drain and refill the front forks with fresh fork oil:
● At every 20,000 mile (32,000 km) service interval.
FORK OIL CHANGE
1. Remove front forks. See 2.17 FRONT FORK.
2. See Figure 1-26. Clamp the fork in a vise with front fork
holding tool (part no. B-4177).
3. See Figure 1-27. Remove slider tube cap.
4. See Figure 1-28. Push down on the B-spring seat (O-
ring included) and remove the stopper ring and spring
seat.
5. See Figure 1-29. Remove the spring collar, lower spring
seat and spring from slider tube.
Figure 1-26. Clamping the Fork
Figure 1-27. Slider Tube Cap
3767
3768
Figure 1-28. B-Spring Seat
Figure 1-29. Removing Sub-Assembly
3769
1. Spring collar
2. Lower spring seat
3. Spring
a0006xSx
1
2
3
