PRIMARY CHAIN 1.12
GENERAL
Adjust primary chain tension:
● At the 1000 mile (1600 km) initial service interval.
● At every 2500 mile (4000 km) interval thereafter.
ADJUSTMENT
See Figure 1-22. Buell Blast Models are shipped with a
spacer between the primary chain limiting screw and the lock-
nut. The spacer is used to quickly get proper adjustment dur-
ing production. This spacer should be removed and discarded
at the first adjustment interval.
1. See Figure 1-22. Back-off jam nut (3) and chain limiting
screw (1).
2. Remove spacer (2).
IMPORTANT NOTE
Be certain to use Inch-Pound Wrench. Chain adjuster
shoe can be damaged by excessive force.
3. See Figure 1-24. Tighten chain limiting screw to 24 in-
lbs (2.7 Nm).
4. Back-off chain limiting screw 3/4 turn (4 1/2 “flats”).
5. Hold chain limiting screw while tightening jam nut.
Figure 1-22. Adjustment Nut-with Spacer
7790
1. Chain limiting screw
2
. Spacer (discard after initial adjustment is made)
3
.Jam nut
2
1
3
Figure 1-23. Chain Limiting Screw-without Spacer
Figure 1-24. Tightening Chain Limiting Screw
7789
7791
