1-26 2003 Buell P3: Maintenance
HOME
REAR SHOCK ABSORBER 1.13
GENERAL
Inspect rear shock absorber for proper operation and for oil
leaks. Inspect rubber shock eye bushings for deterioration:
● At every 10,000 mile (16,000 km) service interval.
NOTE
See Figure 1-25. Damper component (3) cannot be serviced
or repaired. If the damper component is leaking or damaged
it must be replaced.
Figure 1-25. Rear Shock Absorber Assembly
1. Bolt
2. Damper bushing
3. Damper component
4. Nut
5. Stopper ring
6. Spring seat
7. Spring
8. Spring seat stopper
a0015xSx
1
2
3
4
1
2
4
5
6
7
8
