Chapter1 Setup
LinkStation User Manual 16
5 Power LED (LinkStation)
Blue LED: Power on.
LED is o: Power o.
Blinks blue: During startup / shutdown.
6 Security lock for anti-theft
Many security cables are compatible with this lock.
7 USB 2.0 connector
You may attach a USB device such as a digital camera, printer, memory card reader, or hard
drive. USB hubs, mice, keyboards, and all-in-one printers are not supported. USB card
readers that support multiple memory cards may not function properly.
8 Power Mode Switch
AUTO: The LinkStation turns on and o automatically with your PC(s).
ON: The LinkStation boots and is operational.
OFF: The LinkStation shuts down and turns o.
9 Power connector
The AC adaptor connects here.
10 LAN Port
Connect to your LAN with an Ethernet cable.
11 Hook
Secure the Power cable so that it does not come o by mistake. Slide the cable down to
secure.
