Operating Instructions
Busch-Timer
®
Operation
Operating Instructions | 1473-1-8164
— 17 —
Pos: 63 / #Ne ustr ukt ur# /Onl in e-Do kume ntati on (+ KNX) /B edie nung /Ti mer/ Ein st ellu ngen Bl oc k-Prog ra mmier ung - 645 5 Jalous ie @ 28 \mod_1346999606310_15.docx @ 231672 @ 3 @ 1
Fig. 11: Menu item – Block
Sequence of operating steps
Button
Display
Entry / Comments
Switching times
- Press the menu button to switch to the setting mode.
BLOCK
- Press the OK button to select menu item "Block".
The weekdays flash.
- Press the OK button again.
MON--FRI UP / 7:00
The preset up-time flashes.
7:30
- Set the desired up-time via the arrow buttons.
In this example the up-time has been set at 7:30.
MON--FRI down / 20:00
- Confirm your entry with the "OK" button.
You simultaneously switch to the next menu item "Mon - Fri DOWN".
The preset down-time flashes.
20:30
- Set the desired down-time via the arrow buttons.
In this example the down-time has been set at 20:30.
Sat--Sun UP / 08:00
- Press the OK button again.
The preset up-time flashes.
08:30
- Set the desired up-time via the arrow buttons.
In this example the up-time has been set at 8:30.
Sat--Sun down / 21:00
- Confirm your entry with the "OK" button.
You simultaneously switch to the next menu item "Sat - Sun DOWN".
The preset down-time flashes.
21:30
- Set the desired down-time time via the arrow buttons.
In this example the down-time has been set at 21:30.
Switching times
- Confirm your entry with the "OK" button.
The switching times have been set.
- Press the menu button to switch to the operating mode.
