5.5 Overview of the menu structure
Pos: 39 / #Ne ustr ukt ur#/Online-Do kument ation (+KNX) /Bedi enung /Ti mer/Me nüstr uktur 6 455 Jal ousie @ 28\mod_1346926918298_15.docx @ 230393 @ 33333333 @ 1
Menu
Menu items
Indicators
Setting (function)
Language
Country
Select country (language setting).
Switching times
Block
Set switching times for moving the blind up or
down. The same times are taken over for the
days from Monday to Friday.
Mon-Fri UP
Mon–Fri Down
Set switching times for moving the blind up or
down. The same times are taken over for
Saturday and Sunday.
Sat-Sun Up
Sat-Sun Down
Astro
Set a time shift of ±90 minutes. The astro
switching times are pre-programmed; however,
with the shift the switching time can be adapted
to the regional conditions.
Mon-Fri UP
Time shift
Mon–Fri Down
Time shift
Sat-Sun Up
Time shift
Sat-Sun Down
Time shift
Individual
Set the switching times for moving the blind up
or down for each weekday independent of each
other.
Mon UP
Mon Down
Tue Up
Tue Down
:
Date / Time
Day / Month / Year
Set date.
Hours / Minutes
Set time.
Special
functions
Additional switching
times
-- ON
Set an additional up and down command for
each weekday.
Set the time for moving the blind UP. After the
DOWN movement the return travel pulse
causes the blind to move UP for the set time
(e.g. for slat adjustment).
Return pulse 0 … 255
Duration of down
movement
--:--
Set the down movement to move to an
intermediate position of the blind.
Set blocking time, to limit the set astro times.
Astro blocking time UP: "not rather UP than
...".
Astro blocking time DOWN: "not rather DOWN
than ...".
Astro --:--
