Sequence of operating steps
Button
Display
Entry / Comments
Switching times
- Press the menu button to switch to the setting mode.
Special functions
- Select menu "Special functions" via the arrow buttons.
Additional switching
times
- Press the OK button.
Menu item "Additional switching times" is displayed.
Return pulse
- Select menu "Return pulse" via the arrow buttons.
Return pulse switching
times
O 00
- Confirm your selection with the OK button.
You simultaneously switch to the next menu item "Return pulse switching times".
The display flashes.
1 50
- Set a return pulse from 0 to 255 via the arrow buttons.
In this example a return pulse of 150 has been set.
The following menu item is displayed only if "Additional switching times" has been activated.
Additional switching
times for return
pulse
O 00
- Confirm your entry with the "OK" button.
You simultaneously switch to the next menu item "Twilight return pulse".
The display flashes.
1 00
- Set a return pulse from 0 to 255 via the arrow buttons.
In this example a return pulse of 100 has been set.
The following menu items are displayed only if a brightness sensor has been connected.
Twilight return pulse
O 00
- Confirm your entry with the "OK" button.
You simultaneously switch to the next menu item "Twilight return pulse".
The display flashes.
0 60
- Set a return pulse from 0 to 255 via the arrow buttons.
In this example a return pulse of 60 has been set.
Special functions
- Confirm your entry with the "OK" button.
You simultaneously switch to menu "Special functions".
- Press the menu button to switch to the operating mode.
